제품 상세 정보:
결제 및 배송 조건:
|
| 케이블 배출구: | 똑바로 | 이젝터 특성: | 높은 흡입률 |
|---|---|---|---|
| 뇌졸중: | 40mm | 피스톤 직경: | 12 - 63mm |
| 포트 크기: | M5, G1/8, G1/4, G3/8, G1/2 | 재료: | 알류미늄 |
| 위치 감지: | 홀 센서를 통해 | 프로브 재료: | 스테인레스 스틸 |
| 너비: | 20mm | 온도 범위: | -20 ~ 80도 섭씨 |
| 강조하다: | Phoenix Contact surge protection base element,industrial surge protection device,VAL-MS2+0-BE/FM surge protector |
||
Description:
Description: Phoenix
Product No. :2805321
https://www.achievers-automation.com More Products
The Phoenix Contact MCR - SL - R - UI is a high - performance potentiometer position transducer belonging to the MINI MCR product series. With an ultra - slim 6.2mm width, it is specialized in converting potentiometer position signals into standardized analog signals. It is applicable to potentiometers with a resistance range of 100Ω - 100kΩ and supports flexible configuration of output signals via DIP switches. Equipped with 3 - way isolation and automatic potentiometer detection functions, this module is widely used in industrial automation, process control, and machinery monitoring systems. It ensures accurate and stable signal transmission while simplifying debugging and installation processes, which is essential for improving the reliability of industrial control systems.
Detail:
|
Specification Category
|
Details
|
|
Manufacturer
|
Phoenix Contact
|
|
Product Model
|
VAL-MS2+0-BE/FM
|
|
Order Number
|
2805321
|
|
Product Type
|
Type 2 Surge Protection Base Element
|
|
Product Family
|
VALVETRAB MS
|
|
IEC Test Classification
|
II (Type T2)
|
|
EN Type
|
T2
|
|
Number of Positions
|
2
|
|
Nominal Frequency
|
50 Hz (60 Hz compatible)
|
|
Surge Protection Fault Message
|
Remote indication contact (changeover contact)
|
|
Max Continuous Voltage (Uc)
|
500 V AC
|
|
Rated Load Current (IL)
|
80 A
|
|
Attribute
|
Specifications
|
|
Mounting Type
|
DIN Rail Mounting
|
|
Dimensions (W x H x D)
|
35.6 mm x 96.8 mm x 51.5 mm (incl. 7.5 mm DIN rail)
|
|
Housing Material
|
PBT (Polybutylene Terephthalate)
|
|
Color
|
Black (RAL 9005)
|
|
Flammability Rating
|
UL 94 V-0
|
|
Connection Type (Main)
|
Screw connection (M5 thread); Fork-type cable lug compatible
|
|
Conductor Cross-Section (Main)
|
Rigid: 1.5-35 mm²; Flexible: 1.5-25 mm² (AWG 15-2)
|
|
Connection Type (Remote Contact)
|
Plug-in/screw via COMBICON (M2 thread)
|
|
Insulation Characteristics
|
Overvoltage Category III; Pollution Degree 2; CTI value 600
|
Brand
Achievers Automation Limited has more than 10 years experience in the market of Industrial Automation, specialized in reselling factory sealed Probe, Sensor, DCS,isolator barrier, HMI, PLC,Adapter,Profibus connector and cable from Brands as BENTLY NEVADA, E+H, MTL, AB, Pepperl+Fuchs, YOKOGAWA, ASCO, Schneider, Lenze, Pro-face, Mitsubishi, Omron, Lenze, Delta, IFM etc. If you have any request, please do not hesitate to contact us.
Below are the TOP BRANDS we handle in the past 14 years:
FAQ of Achievers
Q:Are the Products Genuine OEM Units?
A: These items have been certified by Achievers Automation Limited to be genuine OEM Units obtained through OEM or independent third-party channels.
Q:How will you arrange shipment?
A: We can arrange shipment based on your request. We have cooperated forwader who can arrange shipment via FedEx, DHL,TNT with good price.
Q:What is the warranty of goods?
A: One-year Warranty.
